Multi-Sensing

MAiRA can see, hear, and feel its environment.

Intelligent

The integrated augmented intelligence enables MAiRA to be used for more applications than any other robot.

Robotic Assistant

MAiRA is created to assist YOU. Everyone can program MAiRA, no coding skills needed.

Multi-sensing

MAiRA can see, hear, and feel its environment.

Intelligent

The integrated augmented intelligence enables MAiRA to be used for more applications than any other robot.

Robotic Assistant

MAiRA is created to assist YOU. Everyone can program MAiRA, no coding skills needed.

Cutting-edge 3D-vision sensor

Gesture control
3D object detection
Ai-powered

Cutting-edge 3D-vision sensor

Gesture control

3D object detection

Ai-powered

MAiRA reaches far

MAiRA S - 1.050 mm
MAiRA M - 1.400 mm
MAiRA L - 1.600 mm

MAiRA reaches far

1.050 mm

1.400 mm

1.600 mm

MAiRA

Human-like voice recognition

With the help of an integrated 360° microphone array and powered by AI, MAiRA can understand your commands, enhancing the user experience even more.

Human-like voice recognition

With the help of an integrated 360° microphone array and powered by AI, MAiRA can understand your commands, enhancing the user experience even more.

MAiRA

Dynamic payload and speed

Up to 4.5 m/s and up to 360°/s
Dynamic payloads: MAiRA S 15-18kg || MAiRA M 12-14kg || MAiRA L 8-11kg

Dynamic payload and speed

Up to 4.5m/s and up to 360°/s || Dynamic payloads: MAiRA S 15-18kg || MAiRA M 12-14kg || MAiRA L 8-11kg

MAiRA’s head;
packed with intelligence

Customizable HMI buttons || 3D Voice Recognition with 360° Microphone Array || 6-DOF Smart Skin for precise hand guiding || 3D Vision Sensor || 6-DOF Force-Torque Sensor

The senses

MAiRA can see, hear, and feel the environment.

Truly cognitive

The integrated AI enables true human-robot collaboration.

MAiRA

The connector flange

ETHERCAT, MODBUS, CAN BUS, IO LINK, GPIO and 3x compressed AIR make MAiRA ready for all tasks imaginable.

The connector flange

ETHERCAT, MODBUS, CAN BUS, IO LINK, GPIO and 3x compressed AIR make MAiRA ready for all tasks imaginable.

IP 65 protected
Dust proof
Water proof

IP 65

Dust
proof

Water
proof

MAiRA

In-house development of
encoders and servos

Gain a competitive edge in precision, speed and repeatability through hardware and software designed by NEURA Robotics.

Encoders & servos developed in-house

Gain a competitive edge in precision, speed and repeatability through hardware and software designed by NEURA Robotics.

Unique, Safe Touchless Human Detection

Touchless sensor technology
Truly collaborative
Reliable in harsh environments

Unique Safe Touchless Human Detection

Touchless sensor tech

Truly colla-borative

Reliable in any env-ironment

MAiRA

Next-level user experience

Create programs within minutes – no coding skills required. Drag and drop action elements and run the program right away.

Next-level user experience

Create programs within minutes - no coding skills required. Drag and drop action elements and run the program right away.

MAiRA specifications

Payload
MAiRA S 15-18kg || MAiRA M 12-14kg || MAiRA L 8-11kg
Reach
MAiRA S 1.050mm || MAiRA M 1.400mm || MAiRA L 1.600mm
Degrees of Freedom

6 or 7 rotating joints

Speed
Up to 4.5m per second || up to 360° per second
Footprint base

Ø 240 mm

Teach pendant
Easy programming of User Interface
Control box
Modular control box for Ai, Safety, Motion, Power
Protection class

IP 65
